DT Research/Configurable
DT Research DT361DM
US · DTR-BASE-DT361DM
Configurable device · Advertised base configuration
Configurable modelDTR-BASE-DT361DM
The hardware
Full Specifications
Configuration choices and fixed specifications. Upgrade limits do not guarantee an orderable choice.
Performance — CPU / GPU▾
| Processor | Intel Core i7-1250U, 10-core, up to 4.70 GHzSource & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Graphics | UnpublishedSource & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Memory & Storage▾
| Installed RAM | 16 GBSource & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|
Documented memory specifications
- 16GB RAM
Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: 16.0 GB.
Manufacturer options ↗Documented storage specifications
Advertised base: Unpublished
- 512GB or 1TB removable SSD
Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: Unpublished.
Manufacturer options ↗Linked memory and storage packages
- 512GB or 1TB removable SSD with 16GB RAM
Exact paired package wording, not independent capacities or a Cartesian combination of choices.
Manufacturer options ↗Linked memory and storage packages
Advertised base: Unpublished
- 512GB or 1TB removable SSD with 16GB RAM
Exact paired package wording, not independent capacities or a Cartesian combination of choices.
Manufacturer options ↗Display▾
| Screen technology | Unpublished |
|---|---|
| Size | 6 inSource & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
| Refresh rate | UnpublishedSource & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Night Vision Screen module options
- Option 1 : Daylight Mode: 800 Nits; NVIS Mode: 0 to 20 Nits. MIL-STD-3009 Class B Compliant, Providing Clear Readability of Display with the Naked Eye in Dark Environments, Does Not Interfere with NVGs.
- Option 2 : Daylight Mode: 800 Nits; NVIS Mode: 0 to 0.7 Nits. MIL-STD-3009 Class B Compliant, Providing Clear Readability of Display with NVGs in Dark Environments.
Optional factory module, not included base hardware or confirmation of every combination.
Manufacturer options ↗Battery & Power▾
| Battery capacity | UnpublishedSource & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Power supply | Input: 100 to 240V AC; Output: 19V DC, 3.42ASource & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Connectivity▾
| Ports | USB Port: 1 x latest USB/charging, 1 x USB-A · Ethernet: Ethernet 10/ 100/ 1000MB Base-T LAN · DC-in Jack: 1Source & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Wireless & networking | WLAN: Wi-Fi 802.11ac, 2.4GHz/ 5GHz dual band · BT: 5.0Source & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Build & Physical▾
| Weight | 454 gSource & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Dimensions | Dimensions (H x W x D): 3.7 x 7.6 x 1.3 in/ 95 x 193 x 32 mmSource & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Software & Bundle▾
| Included bundle | DT361DM complete tablets model; exact ordered accessory bundle is not statedSource & observationView specification source ↗Observed 2026-10-04T02:19:44.630463+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|
Documented operating systems
- Microsoft Windows 10/11 IoT Enterprise operating system
Official shipping OS wording. Different OS alternatives are not a selected base. Versions alone do not block publication. The configurator may narrow currently selectable choices.
Manufacturer options ↗Enclosure and environmental specifications
Enclosure: ABS + PC plastics and magnesium-aluminum alloy | Durability: IP65 and MIL-STD-810H | Regulatory: CE, FCC Class B, RoHS, UL | Temperature: Operation: 0°C to 50°C (32°F to 122°F ) | Temperature: Optional Wider Operating Temperature Range: -30°C to 50°C (-22°F to 122°F) | Temperature: Storage: -50°C to 70°C (-58°F to 158°F) | Humidity: 0% to 90% non-condensing
Manufacturer options ↗Camera module options
- 5 MP front camera and 8 MP back camera
Optional factory module, not included base hardware or confirmation of every combination.
Manufacturer options ↗Independent testing
No published tests or reviewsBenchmarks & Reviews
No test results available (for now). A buying verdict is unavailable for this exact configuration.
