DT Research DT312PA

Documented processor alternatives

Advertised base: Unpublished

• IntelCore Ultra 5 processor 225U, 12 core (up to 4.80 GHz)
• IntelCore Ultra 7 processor 255U, 12 core (up to 5.20 GHz)

Official alternatives without a selected base. No first-listed CPU is assumed installed. Core counts and clock speeds apply to the stated processor.

Configurator processor choices

Advertised base: Unpublished

• Intel Core Ultra 5
• Intel Core Ultra 7

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=333. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Documented memory specifications

Advertised base: Unpublished

• Ultra 5: 16GB LPDDR5
• Ultra 7: 32GB to 64GB LPDDR5
• * The memory is embedded. Alternative configurations are available by special order with MOQ

Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: Unpublished.

Documented storage specifications

Advertised base: Unpublished

• 512GB to 2TB
• *Support quick access SSD function to easily replace the SSD without opening the
• back cover

Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: Unpublished.

Configurator memory choices

Advertised base: Unpublished

• 16GB

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=333. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Configurator primary storage choices

Advertised base: Unpublished

• 512GB
• 1TB
• 2TB

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=333. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Configurator screen choices

• Capacitive Touch

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=333. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

24-pin Fischer Minimax Connector (optional) optional connections

• 1 x USB2.0, COM port, RJ45, Power 5A (in), and Power 2A (out)

Optional module/connector, not an included native port. Interface types and counts are retained.

GNSS module options

• GPS

Optional factory module, not included base hardware or confirmation of every combination.

Mobile Broadband module options

• 4G LTE/AWS

Optional factory module, not included base hardware or confirmation of every combination.

Factory modules for networking

• 5G LTE (EU) (U5G-EU-312P)
• 5G LTE (US) (U5G-US-312P)
• GPS (UGPS-312P)
• 4G LTE (EU) (ULTE-EU-312P)
• 4G LTE (US) (ULTE-US-312P)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=333. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. 5G LTE (EU) (U5G-EU-312P): 5G LTE (EU) | 5G LTE (US) (U5G-US-312P): 5G LTE (US) | GPS (UGPS-312P): GPS | 4G LTE (EU) (ULTE-EU-312P): 4G LTE (EU)Note: can not co-exist with GPS | 4G LTE (US) (ULTE-US-312P): 4G LTE (US) Note: can not co-exist with GPS

Documented operating systems

• Microsoft Windows 11 IoT
• Enterprise

Official shipping OS wording. Different OS alternatives are not a selected base. Versions alone do not block publication. The configurator may narrow currently selectable choices.

Battery alternatives

• 60W Hot-swappable battery (11.4V, 5400mAh)
• 90W Hot-swappable battery, (11.4V, 8000mAh)

Optional packs are not installed by default. Source W is not silently converted to Wh. Wh totals are not inferred from voltage or mAh.

Enclosure and environmental specifications

Enclosure: ABS + PC plastic and magnesium-aluminum alloy | Durability: IP65, MIL-STD-810H and MIL-STD-461G certified | Regulatory: CE, FCC Class B, IC, CB, RCM, IEC 60601-1, IEC62680, | Regulatory: EPEAT, Energy star 9.0 | Temperature: Operation*: -10°C to 60°C (14°F to 140°F) | Temperature: Storage: -50°C to 70°C (-58°F to 158°F) | Humidity: 0% to 90% non-condensing

Barcode Scanner module options

• 2D barcode scanner (reads 1D and 2D)

Optional factory module, not included base hardware or confirmation of every combination.

Camera module options

• 5 MP front camera and 13 MP back camera

Optional factory module, not included base hardware or confirmation of every combination.

Smart Card/CAC Reader module options

• Half-slot (supports ISO 7816 T=0, T=1); 1.8V/3V/5V smart card

Optional factory module, not included base hardware or confirmation of every combination.

NFC/RFID Reader module options

• HF 13.56 MHz, ISO 15693, 14443A(B) and 18000-3 Mode 1

Optional factory module, not included base hardware or confirmation of every combination.

Configurator operating system choices

• WIN 11 IoT

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=333. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Warranty for this model

• Three years of No-Fault Accidents Warranty. (UEW-NFW3-312)
• Five years of No-Fault Accidents Warranty. (UEW-NFW5-312)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=333. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

System upgrades for this model

• Upgrade from 43W battery to 60W battery with new unit purchase (UBATT-004)
• Upgrade from 43W battery to 90W battery with new unit purchase (UBATT-005)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=333. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

Factory modules for this model

• Back camera (UCCD-312PB)
• Front camera (UCCD-312PF)
• Upgrade system with Low Temperature Heat Pad (ULTHP-312P)
• RFID (Raw Data) (URFID-312-R)
• 2D Area Imager Scanner (US2D-312P)
• CAC/Smart Card Reader (USCR-300B)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=333. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Back camera (UCCD-312PB): Back camera | Front camera (UCCD-312PF): Front camera | Upgrade system with Low Temperature Heat Pad (ULTHP-312P): Upgrade system with Low Temperature Heat Pad | RFID (Raw Data) (URFID-312-R): RFID (Raw Data) | 2D Area Imager Scanner (US2D-312P): 2D Area Imager Scanner | CAC/Smart Card Reader (USCR-300B): CAC/Smart Card Reader

Accessories for this model

• Handle kits for 311 & 312 series. Factory installed only (AAC-010-28)
• Handstrap. Designed to securely hold the 312RP series tablets. (AAC-010-312)
• AC Adapter with Power Cord (ACC-001-09)
• Single-bay Battery Charger kit with AC Adapter and Power cord for 43W or 60W or 90W battery (ACC-001-34A)
• Battery Gang Charger. Simultaneously charge 6 of 43W or 60W or 90W batteries (ACC-001-35A)
• Automobile Adapter (ACC-001-59)
• Automobile Adapter (ACC-001-60)
• 461G Power Adapter with Power Cord (ACC-001-67)
• 43W Battery Pack (ACC-006-29)
• 60W Battery Pack (ACC-006-60K)
• 90W Battery Pack (ACC-006-90K)
• Digital Pen (ACC-007-35)
• Shoulder Strap for Tablets (ACC-010-07)
• 11.6” Screen Protector for 311YR/LT320 series (ACC-011-17)
• 11.6” Tempered Glass Screen Protector (2 in 1 package) (ACC-011-28)
• Desktop Charging Cradle (ACC-DC300-B1)
• IP65 rated Slim keyboard (ACC-KB312-B)
• Mini Keyboard (ACC-MK300-BE)
• Wall/Vehicle Mount Cradle for 312RP & 312PA series with keylock. Power supply is not included (ACC-WM210P-12A)
• Wall/Vehicle Mount Cradle for 312RP & 312PA series without keylock. Power supply is not included (ACC-WM210P-12B)
• Wall/Vehicle Mount Cradle for 312PA series (no handle) with I/O Box and keylock. (ACC-WM312-B1)
• Wall/Vehicle Mount Cradle for 312PA series (no handle) without I/O Box, with keylock. (ACC-WM312-B2)
• Wall/Vehicle Mount Cradle for 312PA series (no handle) with I/O Box, without keylock. (ACC-WM312-BA1)
• Wall/Vehicle Mount Cradle for 312PA series (no handle) without I/O Box and keylock. (ACC-WM312-BA2)
• Sealed IP68 Bluetooth keyboard (ATM-ISK31B-BUS)
• Sealed IP68 USB Keyboard (ATM-ISK31BL-BUS)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=333. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Handle kits for 311 & 312 series. Factory installed only (AAC-010-28): Handle kits for 311 & 312 series. Factory installed only | Handstrap. Designed to securely hold the 312RP series tablets. (AAC-010-312): Handstrap. Designed to securely hold the 312RP series tablets. Made of soft plastic, easy to clean. For left- or right-handed users | AC Adapter with Power Cord (ACC-001-09): AC/DC Power Adapter with Power Cord | Single-bay Battery Charger kit with AC Adapter and Power cord for 43W or 60W or 90W battery (ACC-001-34A): Single-bay Battery Charger kit with AC Adapter and Power cord for 43W or 60W or 90W battery | Battery Gang Charger. Simultaneously charge 6 of 43W or 60W or 90W batteries (ACC-001-35A): Battery Gang Charger. Simultaneously charge 6 of 43W or 60W or 90W batteries. Power supply is included. | Automobile Adapter (ACC-001-59): Automobile Adapter. DC-DC; 20.5V 3.42A (70.1W) output 3.28-feet with 1.7x4.75/11mm right-angle plug; 12-30V input 3.28-feet cigarette-plug | Automobile Adapter (ACC-001-60): Automobile Adapter. DC-DC; 20.5V 3.42A (70.1W) output 3.28-feet with 1.7x4.75/11mm right-angle plug; Input 12-30V 3.28-feet with bare wires | 461G Power Adapter with Power Cord (ACC-001-67): 461G Power Adapter with Power Cord | 43W Battery Pack (ACC-006-29): 43W Battery Pack | 60W Battery Pack (ACC-006-60K): 60W Battery Pack | 90W Battery Pack (ACC-006-90K): 90W Battery Pack | Digital Pen (ACC-007-35): Digital Pen | Shoulder Strap for Tablets (ACC-010-07): Shoulder Strap for Tablets. Padded for comfort, provides convenient mobile operation, strap is adjustable. | 11.6” Screen Protector for 311YR/LT320 series (ACC-011-17): 11.6” Screen Protector for 311YR/LT320/312RP series (single-sheet of films) | 11.6” Tempered Glass Screen Protector (2 in 1 package) (ACC-011-28): 11.6” Tempered Glass Screen Protector (2 in 1 package) | Desktop Charging Cradle (ACC-DC300-B1): Desktop Charging Cradle | IP65 rated Slim keyboard (ACC-KB312-B): IP65 rated Slim keyboard | Mini Keyboard (ACC-MK300-BE): Mini Keyboard | Wall/Vehicle Mount Cradle for 312RP & 312PA series with keylock. Power supply is not included (ACC-WM210P-12A): Wall/Vehicle Mount Cradle for 312RP & 312PA series with keylock. Power supply is not included | Wall/Vehicle Mount Cradle for 312RP & 312PA series without keylock. Power supply is not included (ACC-WM210P-12B): Wall/Vehicle Mount Cradle for 312RP & 312PA series without keylock. Power supply is not included | Wall/Vehicle Mount Cradle for 312PA series (no handle) with I/O Box and keylock. (ACC-WM312-B1): Wall/Vehicle Mount Cradle for 312PA series (no handle) with I/O Box and keylock. Power supply is not included | Wall/Vehicle Mount Cradle for 312PA series (no handle) without I/O Box, with keylock. (ACC-WM312-B2): Wall/Vehicle Mount Cradle for 312PA series (no handle) without I/O Box, with keylock. Power supply is not included | Wall/Vehicle Mount Cradle for 312PA series (no handle) with I/O Box, without keylock. (ACC-WM312-BA1): Wall/Vehicle Mount Cradle for 312PA series (no handle) with I/O Box, without keylock. Power supply is not included | Wall/Vehicle Mount Cradle for 312PA series (no handle) without I/O Box and keylock. (ACC-WM312-BA2): Wall/Vehicle Mount Cradle for 312PA series (no handle) without I/O Box and keylock. Power supply is not included | Sealed IP68 Bluetooth keyboard (ATM-ISK31B-BUS): Sealed IP68 Bluetooth keyboard | Sealed IP68 USB Keyboard (ATM-ISK31BL-BUS): Sealed IP68 USB Keyboard
