DT Research/Configurable
DT Research DT362DH
US · DTR-BASE-DT362DH
Configurable device · Advertised base configuration
Configurable modelDTR-BASE-DT362DH
The hardware
Full Specifications
Configuration choices and fixed specifications. Upgrade limits do not guarantee an orderable choice.
Performance — CPU / GPU▾
| Processor | Intel Core i3-N300, 8-core (up to 3.80 GHz)Source & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Graphics | UnpublishedSource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Memory & Storage▾
| Installed RAM | 16 GBSource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|
Documented memory specifications
- 16GB
Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: 16.0 GB.
Manufacturer options ↗Documented storage specifications
- 512GB
Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: 512.0 GB.
Manufacturer options ↗Display▾
| Screen technology | Unpublished |
|---|---|
| Size | 6 inSource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
| Resolution | 2160x1080 pxSource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
| Refresh rate | UnpublishedSource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Battery & Power▾
| Battery capacity | UnpublishedSource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Power supply | Input: 100 to 240V AC; Output: 20V DC, 3.25ASource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Connectivity▾
| Ports | USB Port: 1 x latest USB/chargingSource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|
GNSS module options
- GPS
Optional factory module, not included base hardware or confirmation of every combination.
Manufacturer options ↗Build & Physical▾
| Weight | 485 gSource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Dimensions | Dimensions (H x W x D): 7.6 x 3.7 x 1.2 in/192 x 95 x 31 mmSource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Software & Bundle▾
| Included bundle | DT362DH complete tablets model; exact ordered accessory bundle is not statedSource & observationView specification source ↗Observed 2026-10-04T02:19:39.453751+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|
Documented operating systems
- Microsoft Windows 11 IoT Enterprise
Official shipping OS wording. Different OS alternatives are not a selected base. Versions alone do not block publication. The configurator may narrow currently selectable choices.
Manufacturer options ↗Enclosure and environmental specifications
Enclosure: ABS + PC plastic | Durability: IP65, MIL-STD-810H and MIL-STD-461G certified | Regulatory: CE, FCC Class B, RoHS, UL | Temperature: Operation: 0°C to 50°C (32°F to 122°F ); Storage: -50°C to 70°C (-58°F to 158°F) | Humidity: 0% to 90% non-condensing
Manufacturer options ↗Camera module options
- 5 MP front USB camera and 8 MP back USB camera
Optional factory module, not included base hardware or confirmation of every combination.
Manufacturer options ↗Barcode Scanner module options
- 2D barcode scanner (reads 1D and 2D)
- long range 2D barcode scanner (up to 60ft)
Optional factory module, not included base hardware or confirmation of every combination.
Manufacturer options ↗NFC/RFID Reader module options
- HF 13.56 MHz, ISO 15693, 14443A(B) and 18000-3 Mode 1
Optional factory module, not included base hardware or confirmation of every combination.
Manufacturer options ↗UHF RFID Reader module options
- 865 to 928MHz, EPCglobal Class 1 Gen 2/ISO 18000-6C; 30 ft (9.14m) reading distance with trigger grip
Optional factory module, not included base hardware or confirmation of every combination.
Manufacturer options ↗Certification module options
- C1D2
Optional factory module, not included base hardware or confirmation of every combination.
Manufacturer options ↗Independent testing
No published tests or reviewsBenchmarks & Reviews
No test results available (for now). A buying verdict is unavailable for this exact configuration.
