DT Research DT301YR

Documented processor alternatives

Advertised base: Unpublished

• Intel Core i7-1355U, 10-core, up to 5.0 GHz
• Intel Core i5-1335U, 10-core, up to 4.6 GHz

Official alternatives without a selected base. No first-listed CPU is assumed installed. Core counts and clock speeds apply to the stated processor.

Configurator processor choices

Advertised base: Unpublished

• 13th Gen. Core i5
• 13th Gen. Core i7

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=300. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Documented memory specifications

Advertised base: Unpublished

• 8GB to 32GB

Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: Unpublished.

Documented storage specifications

Advertised base: Unpublished

• 512GB to 2TB flash

Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: Unpublished.

Configurator memory choices

Advertised base: Unpublished

• 8GB

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=300. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Configurator primary storage choices

Advertised base: Unpublished

• 512GB
• 1TB
• 2TB

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=300. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

System upgrades for memory

Advertised base: Unpublished

• Upgrade from 8GB to 16GB RAM (UD8GB-16GB)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=300. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

Configurator screen choices

• Capacitive Touch

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=300. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

GNSS module options

• GPS

Optional factory module, not included base hardware or confirmation of every combination.

Mobile Broadband module options

• 4G LTE/AWS

Optional factory module, not included base hardware or confirmation of every combination.

Factory modules for networking

• GPS ( UGPS-301Y)
• 4G LTE (EU) (ULTE-EU-301Y)
• 4G LTE (US) (ULTE-US-301Y)
• Upgrade system with antenna pass through (UPASS-301Y)
• Micro UHF with Embedded Antenna (URFID-301Y)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=300. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. GPS ( UGPS-301Y): GPS | 4G LTE (EU) (ULTE-EU-301Y): 4G LTE (EU) | 4G LTE (US) (ULTE-US-301Y): 4G LTE (US) | Upgrade system with antenna pass through (UPASS-301Y): Upgrade system with antenna pass through | Micro UHF with Embedded Antenna (URFID-301Y): Micro UHF with Embedded Antenna

Accessories for networking

• Wall/Vehicle Mount Cradle for 301YR series with antenna pass through, but no keylock. (ACC-WM210R-01Y2)
• Wall/Vehicle Mount Cradle for 301YR series with antenna pass through and keylock. (ACC-WM210R-301Y)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=300. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Wall/Vehicle Mount Cradle for 301YR series with antenna pass through, but no keylock. (ACC-WM210R-01Y2): Wall/Vehicle Mount Cradle for 301YR series with antenna pass through, but no keylock. Power supply is not included | Wall/Vehicle Mount Cradle for 301YR series with antenna pass through and keylock. (ACC-WM210R-301Y): Wall/Vehicle Mount Cradle for 301YR series with antenna pass through and keylock. Power supply is not included

Documented operating systems

• Microsoft Windows 10/11 IoT Enterprise

Official shipping OS wording. Different OS alternatives are not a selected base. Versions alone do not block publication. The configurator may narrow currently selectable choices.

Battery alternatives

• 90W Hot-swappable battery (11.4V, 8000mAh)

Optional packs are not installed by default. Source W is not silently converted to Wh. Wh totals are not inferred from voltage or mAh.

Enclosure and environmental specifications

Enclosure: ABS + PC plastic and magnesium-aluminum alloy | Durability: IP65, MIL-STD-810H and MIL-STD-461G certified | Hazard of Electromagnetic Radiation to Ordnance (HERO) Testing: Yes | Regulatory: FCC Class B, CE, RoHS | Temperature: Operation*: -10°C to 60°C (14°F to 140°F) | Temperature: Optional -30°C to 60°C (-22°F to 140°F) with a built-in heating element. | Temperature: Storage: -50°C to 70°C (-58°F to 158°F) | Temperature: *For battery optimal functionality and performance, the recommended usage temperature range is from 0°C to 50°C (32°F to 122°F) | Humidity: 0% to 90% non-condensing

Barcode Scanner module options

• 2D barcode scanner (reads 1D and 2D)

Optional factory module, not included base hardware or confirmation of every combination.

Camera module options

• 5MP front camera and 8MP back camera

Optional factory module, not included base hardware or confirmation of every combination.

UHF RFID Reader module options

• 865 to 928 MHz, EPCglobal Class 1 Gen 2/ISO 18000-6C; 16 ft (4.87m) reading distance

Optional factory module, not included base hardware or confirmation of every combination.

Long Range BT module options

• Class 1 BT (1000 ft)

Optional factory module, not included base hardware or confirmation of every combination.

Certification module options

• C1D2

Optional factory module, not included base hardware or confirmation of every combination.

Configurator operating system choices

• WIN 11 IoT Enterprise

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=300. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Warranty for this model

• Three years no-fault warranty for DT301YR (UEW-NFW3-301)
• Five years no-fault warranty for DT301YR (UEW-NFW5-301)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=300. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

System upgrades for operating system

• For Pentium units with Windows 11 license and Windows 10 downgrade right. New unit purchase only. (DWIN10-EHE)
• For i5 units with Windows 11 license and Windows 10 downgrade right. New unit purchase only. (DWIN10-VHE )

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=300. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

System upgrades for this model

• Upgrade from 60W to 90W battery with new unit purchase (UBATT-001)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=300. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

Factory modules for this model

• Back camera (UCCD-301YB)
• Front camera (UCCD-301YF)
• Long Range Bluetooth (ULRBT-301Y)
• Upgrade system with Low Temperature Heat Pad (ULTHP-301Y)
• 2D Area Imager Scanner (US2D-301Y)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=300. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Back camera (UCCD-301YB): Back camera | Front camera (UCCD-301YF): Front camera | Long Range Bluetooth (ULRBT-301Y): Long Range Bluetooth | Upgrade system with Low Temperature Heat Pad (ULTHP-301Y): Upgrade system with Low Temperature Heat Pad | 2D Area Imager Scanner (US2D-301Y): 2D Area Imager Scanner

Accessories for this model

• Handle kits for 301 series. Factory installed only (AAC-010-29)
• Handstrap for DT301YR (AAC-010-301)
• AC Adapter with Power Cord (ACC-001-09)
• Single-bay Battery Charger kit with AC Adapter and Power cord for 43W or 60W or 90W battery (ACC-001-34A)
• Battery Gang Charger. Simultaneously charge 6 of 43W or 60W or 90W batteries (ACC-001-35A)
• Automobile Adapter (ACC-001-59)
• Automobile Adapter (ACC-001-60)
• 60W Battery Pack (ACC-006-60K)
• 90W Battery Pack (ACC-006-90K)
• Digital Pen (ACC-007-35)
• Pole Mount Cradle for 301YR series (ACC-008-301YPT)
• Shoulder Strap for Tablets (ACC-010-07)
• 10.1” Tempered Glass Screen Protector (ACC-011-27)
• 10.1” Screen Protector for DT301 series (ACC-011-301)
• Desktop Charging Cradle with Battery Charging Slot (ACC-DC212-B01)
• Desktop Charging Cradle without HDMI Output for Y tablet series (ACC-DC213-B0)
• Desktop Charging Cradle with one HDMI Output for Y tablet series (ACC-DC213-B1)
• Slim keyboard for DT301YR series (ACC-KB01YS-01)
• Wall/Vehicle Mount Cradle for 301YR series with keylock. Power supply is not included (ACC-WM210-01Y1)
• Wall/Vehicle Mount Cradle for 301YR series without keylock. Power supply is not included (ACC-WM210-01Y2)
• Sealed IP68 Bluetooth keyboard (ATM-ISK31B-BUS)
• Sealed IP68 USB Keyboard (ATM-ISK31BL-BUS)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=300. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Handle kits for 301 series. Factory installed only (AAC-010-29): Handle kits for 301 series. Factory installed only | Handstrap for DT301YR (AAC-010-301): Handstrap. Designed to securely hold the 301YR series tablets. Made of soft plastic, easy to clean. For left- or right-handed users | AC Adapter with Power Cord (ACC-001-09): AC/DC Power Adapter with Power Cord | Single-bay Battery Charger kit with AC Adapter and Power cord for 43W or 60W or 90W battery (ACC-001-34A): Single-bay Battery Charger kit with AC Adapter and Power cord for 43W or 60W or 90W battery | Battery Gang Charger. Simultaneously charge 6 of 43W or 60W or 90W batteries (ACC-001-35A): Battery Gang Charger. Simultaneously charge 6 of 43W or 60W or 90W batteries. Power supply is included. | Automobile Adapter (ACC-001-59): Automobile Adapter. DC-DC; 20.5V 3.42A (70.1W) output 3.28-feet with 1.7x4.75/11mm right-angle plug; 12-30V input 3.28-feet cigarette-plug | Automobile Adapter (ACC-001-60): Automobile Adapter. DC-DC; 20.5V 3.42A (70.1W) output 3.28-feet with 1.7x4.75/11mm right-angle plug; Input 12-30V 3.28-feet with bare wires | 60W Battery Pack (ACC-006-60K): 60W Battery Pack | 90W Battery Pack (ACC-006-90K): 90W Battery Pack | Digital Pen (ACC-007-35): Digital Pen | Pole Mount Cradle for 301YR series (ACC-008-301YPT): Pole Mount Cradle for 301YR series | Shoulder Strap for Tablets (ACC-010-07): Shoulder Strap for Tablets. Padded for comfort, provides convenient mobile operation, strap is adjustable. | 10.1” Tempered Glass Screen Protector (ACC-011-27): 10.1” Tempered Glass Screen Protector (2 in 1 package) | 10.1” Screen Protector for DT301 series (ACC-011-301): 10.1” Screen Protector (single-sheet of film) | Desktop Charging Cradle with Battery Charging Slot (ACC-DC212-B01): Desktop Charging Cradle with Battery Charging Slot for 301YR series | Desktop Charging Cradle without HDMI Output for Y tablet series (ACC-DC213-B0): Desktop Charging Cradle without HDMI Output for Y tablet series | Desktop Charging Cradle with one HDMI Output for Y tablet series (ACC-DC213-B1): Desktop Charging Cradle with one HDMI Output for Y tablet series | Slim keyboard for DT301YR series (ACC-KB01YS-01): Slim keyboard for 301YR series | Wall/Vehicle Mount Cradle for 301YR series with keylock. Power supply is not included (ACC-WM210-01Y1): Wall/Vehicle Mount Cradle for 301YR series with keylock. Power supply is not included | Wall/Vehicle Mount Cradle for 301YR series without keylock. Power supply is not included (ACC-WM210-01Y2): Wall/Vehicle Mount Cradle for 301YR series without keylock. Power supply is not included | Sealed IP68 Bluetooth keyboard (ATM-ISK31B-BUS): Sealed IP68 Bluetooth keyboard | Sealed IP68 USB Keyboard (ATM-ISK31BL-BUS): Sealed IP68 USB Keyboard

Accessories for operating system

• Standalone Windows 11 IoT Enterprise General Availability Channel (GAC) High-End EPKEA license. (ZCLI-001-49)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=300. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Standalone Windows 11 IoT Enterprise General Availability Channel (GAC) High-End EPKEA license. (ZCLI-001-49): Standalone Windows 11 IoT Enterprise General Availability Channel (GAC) High-End EPKEA license.
