DT Research LT355

Documented processor alternatives

Advertised base: Unpublished

• Intel Core i5-1340P, 12-core, up to 4.6 GHz
• Intel Core i7-1370P, 14-core, up to 5.2 GHz

Official alternatives without a selected base. No first-listed CPU is assumed installed. Core counts and clock speeds apply to the stated processor.

Graphic Card module options

Advertised base: Unpublished

• embedded MXM GPU module with embedded NVIDIA RTX A1000 or A2000 MXM

Optional factory module, not included base hardware or confirmation of every combination.

Configurator processor choices

Advertised base: Unpublished

• 13th Gen. i5
• 13th Gen. i7

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=296. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

System upgrades for graphics

Advertised base: Unpublished

• Upgrade to NVIDIA A2000 (UA2000-355)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=296. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

Documented memory specifications

Advertised base: Unpublished

• 8GB to 64GB (dual-slot)

Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: Unpublished.

Documented storage specifications

Advertised base: Unpublished

• 512GB to 2TB SSD

Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: Unpublished.

Configurator memory choices

Advertised base: Unpublished

• 8GB

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=296. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Configurator primary storage choices

Advertised base: Unpublished

• 512GB
• 1TB
• 2TB

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=296. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

System upgrades for memory

Advertised base: Unpublished

• Upgrade from 8GB to 16GB RAM (UD8GB-16GB)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=296. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

Night Vision Screen / Luminance module options

• Option 1: Daylight mode: 800 nits; NVIS mode: 0 to 20 nits. MIL-STD-3009 Class B compliant, providing clear readability of display with the naked eye in dark environments, does not interfere with NVGs.
• Option 2: Daylight mode: 800 nits; NVIS mode: 0 to 0.7 nits. MIL-STD-3009 Class B compliant, providing clear readability of display with NVGs in dark environments.

Optional factory module, not included base hardware or confirmation of every combination.

Configurator screen choices

• Capacitive Touch

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=296. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Accessories for connections

• USB-C I/O ports station (ACC-001-55 )

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=296. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. USB-C I/O ports station (ACC-001-55 ): USB-C I/O ports station. A 90W 19V adapter is included

Documented operating systems

• Microsoft Windows 10/11 IoT Enterprise

Official shipping OS wording. Different OS alternatives are not a selected base. Versions alone do not block publication. The configurator may narrow currently selectable choices.

Battery alternatives

• 2 x 90W Hot-swappable batteries (11.4V, 8000mAh)

Optional packs are not installed by default. Source W is not silently converted to Wh. Wh totals are not inferred from voltage or mAh.

Enclosure and environmental specifications

Enclosure: ABS + PC plastic and magnesium-aluminum alloy | Durability: IP65 | Certifications: FCC Class B, CE, IC, CB, RoHS, EPEAT, RCM compliant | Temperature: Operation: -10°C to 60°C (14°F to 140°F), Optional: -30°C to 60°C (-22°F to 140°F) | Temperature: Storage: -55°C to 70°C (-67°F to 158°F) | Humidity: 0% to 90% non-condensing

Configurator operating system choices

• WIN 11 IoT Enterprise

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=296. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Warranty for this model

• Three years of No-Fault Accidents Warranty. (UEW-NFW3-LTA1)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=296. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

System upgrades for this model

• Upgrade to two of 90W batteries with new unit purchase (UBATT-003)
• Upgrade system with Low Temperature Heat Pad (ULTHP-355)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=296. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

Accessories for this model

• Single-bay Battery Charger kit with AC Adapter and Power cord for 43W or 60W or 90W battery (ACC-001-34A)
• Battery Gang Charger. Simultaneously charge 6 of 43W or 60W or 90W batteries (ACC-001-35A)
• 19V, 230W Adapter with Power Cord for 340TA and LT355 with GPU. (ACC-001-63)
• 60W Battery Pack (ACC-006-60K)
• 90W Battery Pack (ACC-006-90K)
• Digital Pen (ACC-007-35)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=296. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Single-bay Battery Charger kit with AC Adapter and Power cord for 43W or 60W or 90W battery (ACC-001-34A): Single-bay Battery Charger kit with AC Adapter and Power cord for 43W or 60W or 90W battery | Battery Gang Charger. Simultaneously charge 6 of 43W or 60W or 90W batteries (ACC-001-35A): Battery Gang Charger. Simultaneously charge 6 of 43W or 60W or 90W batteries. Power supply is included. | 19V, 230W Adapter with Power Cord for 340TA and LT355 with GPU. (ACC-001-63): 19V, 230W Adapter with Power Cord for 340TA and LT355 with GPU. | 60W Battery Pack (ACC-006-60K): 60W Battery Pack | 90W Battery Pack (ACC-006-90K): 90W Battery Pack | Digital Pen (ACC-007-35): Digital Pen
