DT Research 306Q

Documented memory specifications

• 4GB

Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: 4.0 GB.

Documented storage specifications

• 64GB flash

Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: 64.0 GB.

Configurator memory choices

• 4GB

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=239. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Configurator primary storage choices

• 64GB

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=239. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Configurator screen choices

• Capacitive Touch

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=239. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

GNSS module options

• GPS

Optional factory module, not included base hardware or confirmation of every combination.

Mobile Broadband module options

• 4G LTE/AWS

Optional factory module, not included base hardware or confirmation of every combination.

Factory modules for networking

• GPS (UGPS-306Q)
• 4G LTE (US) (ULTE-US-306Q)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=239. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. GPS (UGPS-306Q): GPS | 4G LTE (US) (ULTE-US-306Q): 4G LTE (US)

Accessories for connections

• AC/DC Power Adapter (65W) with Power Cord, USB-C Plug (ACC-001-38)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=239. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. AC/DC Power Adapter (65W) with Power Cord, USB-C Plug (ACC-001-38): AC/DC Power Adapter (65W) with Power Cord, USB-C Plug

Documented operating systems

• Android 9.0 and 10

Official shipping OS wording. Different OS alternatives are not a selected base. Versions alone do not block publication. The configurator may narrow currently selectable choices.

Enclosure and environmental specifications

Enclosure: ABS + PC plastics | Vibration and Shock Resistance: MIL-STD-810G | Regulatory: FCC Class B, CE, RoHS compliant | Temperature: Operation: 14°F to 122°F (-10°C to 50°C); | Temperature: Storage: -50°C to 70°C (-58°F to 158°F) | Humidity: 0% to 90% non-condensing

Magnetic Stripe Reader module options

• Triple track readers (ISO TK1, 2 and 3), JIS and AAMVA compliant

Optional factory module, not included base hardware or confirmation of every combination.

Barcode Scanner module options

• 2D barcode scanner; reads 1D also

Optional factory module, not included base hardware or confirmation of every combination.

NFC/RFID Reader module options

• HF 13.56MHz, ISO Standard 15693, 14443A(B) & 18000-3 Mode-1

Optional factory module, not included base hardware or confirmation of every combination.

Configurator operating system choices

• Android

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=239. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Factory modules for this model

• Back camera (UCCD-306QB)
• MSR (UMSR-306Q)
• NFC (UNFC-306Q)
• Barcode scanner for DT306Q (US2D-306Q)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=239. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Back camera (UCCD-306QB): Back camera | MSR (UMSR-306Q): MSR | NFC (UNFC-306Q): NFC | Barcode scanner for DT306Q (US2D-306Q): 2D Barcode scanner

Accessories for this model

• Battery Pack (ACC-006-27)
• Digital Pen (ACC-007-35)
• Desktop Cradle (ACC-DC206-01)
• 4-Bay System Gang Charger (ACC-GC206-01)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=239. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Battery Pack (ACC-006-27): Battery Pack | Digital Pen (ACC-007-35): Digital Pen | Desktop Cradle (ACC-DC206-01): Desktop Cradle | 4-Bay System Gang Charger (ACC-GC206-01): 4-Bay System Gang Charger
