DT Research/Configurable
DT Research DT361AM
US · DTR-BASE-DT361AM
Configurable device · Advertised base configuration
Configurable modelDTR-BASE-DT361AM
The hardware
Full Specifications
Configuration choices and fixed specifications. Upgrade limits do not guarantee an orderable choice.
Performance — CPU / GPU▾
| Processor | Intel Core i7-10510Y, Quad-core, 1.2GHz (up to 4.5GHz)Source & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Graphics | UnpublishedSource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Memory & Storage▾
| Installed RAM | 16 GBSource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|
Documented memory specifications
- 16GB RAM
Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: 16.0 GB.
Manufacturer options ↗Documented storage specifications
- 512GB flash
Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: 512.0 GB.
Manufacturer options ↗Linked memory and storage packages
- 512GB flash with 16GB RAM
Exact paired package wording, not independent capacities or a Cartesian combination of choices.
Manufacturer options ↗Linked memory and storage packages
- 512GB flash with 16GB RAM
Exact paired package wording, not independent capacities or a Cartesian combination of choices.
Manufacturer options ↗Display▾
| Screen technology | Unpublished |
|---|---|
| Size | 6 inSource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
| Refresh rate | UnpublishedSource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Night Vision Screen module options
- Option 1 : Daylight Mode: 800 Nits; NVIS Mode: 0 to 20 Nits. MIL-STD-3009 Class B Compliant, Providing Clear Readability of Display with the Naked Eye in Dark Environments, Does Not Interfere with NVGs.
- Option 2 : Daylight Mode: 800 Nits; NVIS Mode: 0 to 0.7 Nits. MIL-STD-3009 Class B Compliant, Providing Clear Readability of Display with NVGs in Dark Environments.
Optional factory module, not included base hardware or confirmation of every combination.
Manufacturer options ↗Battery & Power▾
| Battery capacity | UnpublishedSource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Power supply | Input: 100 to 240V AC; Output: 15V DC, 3ASource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Connectivity▾
| Ports | USB Port: 1 x USB 3.0, 1 x latest USB/charging · Ethernet: Ethernet 10/ 100/ 1000MB Base-T LANSource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Wireless & networking | WLAN: Wi-Fi 802.11ac, 2.4GHz/ 5GHz dual bandSource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Build & Physical▾
| Weight | 454 gSource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|---|
| Dimensions | Dimensions (H x W x D): 3.7 x 7.6 x 1.3 in/ 95 x 193 x 32 mmSource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
Software & Bundle▾
| Included bundle | DT361AM complete tablets model; exact ordered accessory bundle is not statedSource & observationView specification source ↗Observed 2026-10-04T02:19:44.591594+00:00 Exact current official model technical rows; optional hardware and unselected choices separated |
|---|
Documented operating systems
- Microsoft Windows 10/11 IoT Enterprise operating system
Official shipping OS wording. Different OS alternatives are not a selected base. Versions alone do not block publication. The configurator may narrow currently selectable choices.
Manufacturer options ↗Enclosure and environmental specifications
Enclosure: ABS + PC plastics and magnesium-aluminum alloy | Durability: IP65 and MIL-STD-810H | Regulatory: FCC Class B, CE, RoHS compliant | Temperature: Operation: -10°C to 50°C (14°F to 122°F ); | Temperature: Storage: -50°C to 70°C (-58°F to 158°F) | Humidity: 0% to 90% non-condensing
Manufacturer options ↗Independent testing
No published tests or reviewsBenchmarks & Reviews
No test results available (for now). A buying verdict is unavailable for this exact configuration.
