DT Research 139M

Documented processor alternatives

Advertised base: Unpublished

• Intel Pentium Gold-G6400T, 2-core, 3.4 GHz
• Intel Core i5-10500T, 6-core, 2.3 GHz (up to 3.8 GHz)
• Intel Core i5-10600T, 6-core, 2.4 GHz (up to 4.0 GHz)
• Intel Core i7-10700T, 8-core, 2.0 GHz (up to 4.5 GHz)
• Intel Core i9-10900T, 10-core, 1.9 GHz (up to 4.6 GHz)

Official alternatives without a selected base. No first-listed CPU is assumed installed. Core counts and clock speeds apply to the stated processor.

Configurator processor choices

Advertised base: Unpublished

• Core i5
• Core i7

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=276. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Documented memory specifications

Advertised base: Unpublished

• 8GB to 64GB (Dual-Slot)

Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: Unpublished.

Documented storage specifications

Advertised base: Unpublished

• 512GB to 4TB flash

Official technical ranges, CPU-dependent capacity and special-order conditions. A range is not an installed capacity or an invented list of intermediate orderable sizes. Selected base: Unpublished.

Configurator memory choices

Advertised base: Unpublished

• 8GB
• 16GB

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=276. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

Configurator primary storage choices

Advertised base: Unpublished

• 512GB

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=276. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

WLAN optional connections

• 2 x Wi-Fi dipole antenna

Optional module/connector, not an included native port. Interface types and counts are retained.

Network Interface optional networking

• Wi-Fi 802.11ax, 2.4/5 GHz dual band

Optional radios and antenna modules are not included networking.

Factory modules for networking

• Wi-Fi kits with two external antenna (UWIFI-139M)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=276. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Wi-Fi kits with two external antenna (UWIFI-139M): Wi-Fi kits with two external antenna

Documented operating systems

Advertised base: Unpublished

• Microsoft Windows 10/11 IoT Enterprise or Ubuntu

Official shipping OS wording. Different OS alternatives are not a selected base. Versions alone do not block publication. The configurator may narrow currently selectable choices.

Enclosure and environmental specifications

Kensington Lock: 1 | Fan/ Fanless: Fanless | Enclosure: Aluminum alloy with antimicrobial enclosure | VESA-compliant Mounting: 75 x 75 mm/100 × 100mm | Regulatory: ANSI/AAMI ES60601-1, IEC60601-1-2, FCC Part 18, FCC Part 15 Class B, CE-EMC, CE-RED, IEC 62368-1, RCM, CCC | Temperature: Operation: -10°C to 50°C (14°F to 122°F); Storage: -20°C to 60°C (-4°F to 140°F) | Humidity: 0% to 90% non-condensing

Configurator operating system choices

Advertised base: Unpublished

• Ubuntu
• Win 11 IoT Enterprise

Visible controls on https://www.dtresearch.com/productconfig/config.php?model=276. No order or selection was submitted. Choices depend on OS, processor, upgrades and modules; not all combinations are confirmed. Generic CPU tiers do not override detailed official CPU names. Technical limits/special-order ranges are documented separately.

System upgrades for operating system

Advertised base: Unpublished

• For Pentium units with Windows 11 license and Windows 10 downgrade right. New unit purchase only. (DWIN10-EHE)
• For i5 units with Windows 11 license and Windows 10 downgrade right. New unit purchase only. (DWIN10-VHE )

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=276. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained.

Accessories for this model

• Medical Grade AC Adapter with Power Cord (ACC-001-28)
• Parking Stand (ACC-008-118)
• VESA Mounting Bracket (CCH-139M-01)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=276. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Medical Grade AC Adapter with Power Cord (ACC-001-28): Medical Grade 120W AC/DC Adapter with Power Cord | Parking Stand (ACC-008-118): Parking Stand | VESA Mounting Bracket (CCH-139M-01): VESA Mounting Bracket

Accessories for operating system

Advertised base: Unpublished

• Standalone Windows 11 IoT Enterprise General Availability Channel (GAC) High-End EPKEA license. (ZCLI-001-49)

Exact linked controls on https://www.dtresearch.com/productconfig/config.php?model=276. Optional add-ons are not included base hardware. Additional SSDs stay separate from primary drive capacity. License upgrades/downgrade rights do not select a shipping OS. Regional US/EU LTE distinctions are retained. Standalone Windows 11 IoT Enterprise General Availability Channel (GAC) High-End EPKEA license. (ZCLI-001-49): Standalone Windows 11 IoT Enterprise General Availability Channel (GAC) High-End EPKEA license.
