DURABOOK R8-EX Rugged Tablet

Processor choices

Advertised base: Unpublished

• Intel Core i7-1250U (12th Gen) Processor with vPro (12MB Cache, up to 4.7 GHz, 2P+8E cores)
• Intel Core i5-1230U (12th Gen) Processor with vPro (12MB Cache, up to 4.4 GHz, 2P+8E cores)
• Intel Pentium Gold Processor 8500 (8MB Cache, up to 4.4 GHz, 1P+4E cores)

The source lists these CPUs without a selected base. No first-listed CPU is assumed installed. GPS/WWAN and dedicated GPS are mutually exclusive. | Mutually exclusive options. | Tested using the MobileMark 2014 battery life benchmark and using no cellular mobile broadband. Results may vary under different situations including hardware configuration, software, operating conditions, power management settings and other factors. | The system will stay operating (within 300 seconds in standby mode) when user swaps the battery.

Memory choices and supported range

Advertised base: Unpublished

• Onboard 8GB up to 16GB (LPDDR4x)

Official memory range, slot/onboard/package arrangement and maximum. Intermediate sizes are not inferred; RAM on package depends on the selected CPU. No installed capacity is selected by this range.

Storage choices

• 128GB NVMe PCIe SSD
• Optional 256GB/512GB/1TB PCIe SSD

Official standard drive and optional primary/secondary drive choices. A secondary drive is not included in the standard capacity.

I/O Ports options

• Optional USB 3.2 Gen1 (type A) x 1
• Optional 1D/2D barcode reader x 1

Documented official factory choices and limits. Final selections and compatibility depend on the complete build; confirm availability with DURABOOK.

Wireless & Communications options

• Optional dedicated GPS module
• Optional GPS and 4G LTE multi-carrier mobile broadband

Documented official factory choices and limits. Final selections and compatibility depend on the complete build; confirm availability with DURABOOK.

Manufacturer compatibility and specification notes

GPS/WWAN and dedicated GPS are mutually exclusive. | Mutually exclusive options. | Tested using the MobileMark 2014 battery life benchmark and using no cellular mobile broadband. Results may vary under different situations including hardware configuration, software, operating conditions, power management settings and other factors. | The system will stay operating (within 300 seconds in standby mode) when user swaps the battery.

Display and touch options

• 8.0" LCD (1280 x 800)
• 800 nits DynaVue sunlight readable display with capacitive multi-touch screen
• Optional with digitizer
• User selectable touch mode for Finger/Water, Glove or Stylus programmable function

Documented official factory choices and limits. Final selections and compatibility depend on the complete build; confirm availability with DURABOOK.

Camera options

• Optional 11.0 MP auto-focus rear camera with flash

Documented official factory choices and limits. Final selections and compatibility depend on the complete build; confirm availability with DURABOOK.

Battery and power options

• Optional long life battery Li-Ion 7.6V, 7200mAh, 17 hours
• Optional swappable battery: 5 minutes swap time

Documented official factory choices and limits. Final selections and compatibility depend on the complete build; confirm availability with DURABOOK.

Ruggedness and certifications

MIL-STD-810H certified (Drop, Shock, Vibration, Rain, Dust, Altitude, Freeze/Thaw, High/Low Temperature, Temperature Shock, Humidity, Explosive Atmosphere, Salt Fog) | ATEX Zone 2/22 certified | Ex II 3G Ex ic IIC T4 Gc | Ex II 3D Ex ic IIIB T135°C Dc | 6′ drop 26 faces | IP 66 certified | Magnesium alloy chassis | Port covers | Sunlight readable display | Optional swappable battery technology

Warranty details

3-Year Accidental Damage Warranty

Documented accessories

• 65W AC Adapter with power cord
• ATEX Protection Case R8-EX
• Battery Charger - 2 bays
• Battery Charger - 8 bays
• Hand Strap R8
• Screen Protector Film R8-EX
• Shoulder Strap (2 Point)
• Shoulder Strap (4 Point) R8
• Spare Digitizer Pen
• Spare Hi-Cap Battery R8
• Spare Main Battery R8
• Spare Stylus & Tether for capacitive touch
• Tablet Stand
• USB-C AC Adapter with power cord

Accessories are separate add-ons, not standard included hardware. Model-specific restrictions apply.
