Puget Systems/Configurable
Puget Workstation R132-XL
US · PUGET-BASE-547
Configurable desktop · Advertised base configuration
Configurable modelPUGET-BASE-547
The hardware
Full Specifications
Configuration choices and fixed specifications. Upgrade limits do not guarantee an orderable choice.
Performance — CPU / GPU▾
CPU options
- AMD Ryzen 7 9700X 3.8GHz (Up To 5.5GHz Turbo) 8 Core
- AMD Ryzen 9 9900X 4.4GHz (Up To 5.6GHz Turbo) 12 Core
- AMD Ryzen 7 9800X3D 4.7GHz (Up To 5.2GHz Turbo) 8 Core
- AMD Ryzen 9 9900X3D 4.4GHz (Up To 5.6GHz Turbo) 12 Core
- AMD Ryzen 9 9950X 4.3GHz (Up To 5.7GHz Turbo) 16 Core
- AMD Ryzen 9 9950X3D 4.3GHz (Up To 5.7GHz Turbo) 16 Core
- AMD Ryzen 9 9950X3D2 Dual Edition 4.3GHz (Up To 5.6GHz Turbo) 16 Core
Official model choices. Selected base: AMD Ryzen 7 9700X 3.8GHz (Up To 5.5GHz Turbo) 8 Core. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Video Card options
- Onboard Video
- NVIDIA GeForce RTX 5060 Ti 8GB IN STOCK
- NVIDIA GeForce RTX 5070 12GB IN STOCK
- AMD Radeon RX 9070 XT 16GB
- NVIDIA GeForce RTX 5070 Ti 16GB IN STOCK
- NVIDIA GeForce RTX 5080 16GB IN STOCK
- NVIDIA GeForce RTX 5090 32GB CALL FOR AVAILABILITY
- NVIDIA RTX A1000 8GB Quad-Display
- Intel Arc Pro B70 32GB CALL FOR AVAILABILITY
- AMD Radeon AI PRO R9700 32GB
- NVIDIA RTX PRO 2000 Blackwell 16GB
- NVIDIA RTX PRO 4000 Blackwell 24GB
- NVIDIA RTX PRO 4500 Blackwell 32GB IN STOCK
- NVIDIA RTX PRO 5000 Blackwell 48GB IN STOCK
- NVIDIA RTX PRO 5000 Blackwell 72GB
- NVIDIA RTX PRO 6000 Blackwell Max-Q Workstation Edition 96GB
- NVIDIA RTX PRO 6000 Blackwell Workstation Edition 96GB IN STOCK
Official model choices. Selected base: NVIDIA GeForce RTX 5060 Ti 8GB IN STOCK. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Accelerators options
- None
- NVIDIA GeForce RTX 5070 12GB IN STOCK
- NVIDIA GeForce RTX 5070 Ti 16GB IN STOCK
- NVIDIA GeForce RTX 5080 16GB IN STOCK
- Intel Arc Pro B70 32GB CALL FOR AVAILABILITY
- AMD Radeon AI PRO R9700 32GB
- NVIDIA RTX PRO 2000 Blackwell 16GB
- NVIDIA RTX PRO 4000 Blackwell 24GB
- NVIDIA RTX PRO 4500 Blackwell 32GB IN STOCK
- NVIDIA RTX PRO 5000 Blackwell 48GB IN STOCK
- NVIDIA RTX PRO 5000 Blackwell 72GB
- NVIDIA RTX PRO 6000 Blackwell Max-Q Workstation Edition 96GB
Official model choices. Selected base: None. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Memory & Storage▾
| Installed RAM | 32GB (2 X 16GB)Source & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Puget Systems exact official advertised base and selected component controls View RAM layout source ↗ Observed 2026-10-03T02:42:02.965142+00:00 Installed RAM modules stated for the exact product or selected build View RAM stick count source ↗ Observed 2026-10-03T02:42:02.965142+00:00 Installed RAM modules stated for the exact product or selected build |
|---|
RAM options
- 32GB DDR5 UDIMM (2 x 16GB)
- 64GB DDR5 UDIMM (4 x 16GB)
- 64GB DDR5 UDIMM (2 x 32GB)
- 96GB DDR5 UDIMM (2 x 48GB) BEST VALUE
- 128GB DDR5 UDIMM (2 x 64GB)
- 128GB DDR5 UDIMM (4 x 32GB)
- 192GB DDR5 UDIMM (4 x 48GB) BEST VALUE
- 256GB DDR5 UDIMM (4 x 64GB)
Official model choices. Selected base: 32GB DDR5 UDIMM (2 x 16GB). Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Hard Drive options
- 1TB NVMe PCIe Gen4 M.2 SSD
- 1TB NVMe PCIe Gen5 M.2 SSD
- 2TB NVMe PCIe Gen4 M.2 SSD
- 2TB NVMe PCIe Gen5 M.2 SSD
- 4TB NVMe PCIe Gen4 M.2 SSD
- 4TB NVMe PCIe Gen5 M.2 SSD
- 8TB NVMe PCIe Gen5 M.2 SSD
- 1TB SATA SSD
- 4TB SATA SSD
- 8TB SATA SSD
Official model choices. Selected base: 1TB NVMe PCIe Gen4 M.2 SSD. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Second Hard Drive options
- None
- 1TB NVMe PCIe Gen4 M.2 SSD
- 2TB NVMe PCIe Gen4 M.2 SSD
- 4TB NVMe PCIe Gen4 M.2 SSD
- 8TB NVMe PCIe Gen5 M.2 SSD
- 1TB SATA SSD
- 4TB SATA SSD
- 8TB SATA SSD
Official model choices. Selected base: None. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Third Hard Drive options
- None
- 1TB NVMe PCIe Gen4 M.2 SSD
- 2TB NVMe PCIe Gen4 M.2 SSD
- 4TB NVMe PCIe Gen4 M.2 SSD
- 8TB NVMe PCIe Gen5 M.2 SSD
- 1TB SATA SSD
- 4TB SATA SSD
- 8TB SATA SSD
- 12TB 7200 RPM SATA Hard Drive
- 20TB 7200 RPM SATA Hard Drive
- 24TB 7200 RPM SATA Hard Drive
Official model choices. Selected base: None. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Fourth Hard Drive options
- None
- 1TB SATA SSD
- 4TB SATA SSD
- 8TB SATA SSD
- 12TB 7200 RPM SATA Hard Drive
- 20TB 7200 RPM SATA Hard Drive
- 24TB 7200 RPM SATA Hard Drive
Official model choices. Selected base: None. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Display▾
| Screen technology | Not applicable |
|---|---|
| Size | Not applicableSource & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Puget Systems exact official advertised base and selected component controls |
| Resolution | Not applicableSource & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Puget Systems exact official advertised base and selected component controls |
| Refresh rate | Not applicableSource & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Puget Systems exact official advertised base and selected component controls |
Battery & Power▾
| Battery capacity | UnpublishedSource & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Puget Systems exact official advertised base and selected component controls |
|---|---|
| Power supply | Super Flower LEADEX Titanium 1700W (Cybenetics Titanium)Source & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Puget Systems exact official advertised base and selected component controls |
Connectivity▾
| Ports | Motherboard video connectors (CPU and firmware dependent); HDMI: 1 · Motherboard video connectors (CPU and firmware dependent); HDMI Version: 2.0 · Motherboard video connectors (CPU and firmware dependent); DisplayPort: 1 · Motherboard video connectors (CPU and firmware dependent); Notes: Display Port In - usable with dedicated GPU and USB4 display · Motherboard rear ports; USB 2.0: 1 · Motherboard rear ports; USB 3.2 Gen 2 (USB 3.1): 7 · Motherboard rear ports; USB 4: 2 · Motherboard rear ports; USB 3.2 Gen 2x2 Type C: 1 · Motherboard rear ports; Audio Out: Stereo · Motherboard rear ports; Audio In: Line-In/Microphone · Motherboard rear ports; LAN (RJ45): 2 · Motherboard rear ports; Wireless Antenna Port: Yes · Motherboard rear ports; BIOS Flashback: Yes · Graphics outputs per card; Port 1: HDMI 2.1b · Graphics outputs per card; Port 2: DisplayPort 2.1b · Graphics outputs per card; Port 3: DisplayPort 2.1b · Graphics outputs per card; Port 4: DisplayPort 2.1b · Chassis front ports; USB 2.0: 2 · Chassis front ports; USB 3.0: 2 · Chassis front ports; Audio In: 1 · Chassis front ports; Audio Out: 1 · Chassis front ports; USB-C: 1Source & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Puget Systems exact official advertised base and selected component controls |
|---|
Networking options
- Integrated Ethernet, WiFi, and Bluetooth
- Intel E810 Dual 25/10GbE SFP28 PCIe x8
Official model choices. Selected base: Integrated Ethernet, WiFi, and Bluetooth. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Build & Physical▾
| Weight | UnpublishedSource & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Puget Systems exact official advertised base and selected component controls |
|---|---|
| Dimensions | UnpublishedSource & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Puget Systems exact official advertised base and selected component controls |
Software & Bundle▾
| Included bundle | Unpublished |
|---|
CD / DVD options
- None
- Blu-ray Burner SATA
Official model choices. Selected base: None. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗OS options
- Linux - Ubuntu 24.04 LTS 64-bit Installation w/ Gnome Desktop [LIMITED SUPPORT]
- Linux - Ubuntu 26.04 LTS 64-bit Installation w/ Gnome Desktop [LIMITED SUPPORT]
- Windows 11 Pro 64-bit
Official model choices. Selected base: Windows 11 Pro 64-bit. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Services options
- Paperless Packet
- Provide All Unused Component Accessories
- Provide All Unused Power Cables
- Provide Complimentary DisplayPort Cable
- Provide Complimentary HDMI Cable (GeForce/Radeon/Intel only)
- WiFi / Bluetooth Replacement Service (Linux only)
Official model choices. Selected base: Paperless Packet. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Warranty options
- Lifetime Labor and Tech Support, 1 Year Parts Warranty
- Lifetime Labor and Tech Support, 2 Year Parts Warranty
- Lifetime Labor and Tech Support, 3 Year Parts Warranty
Official model choices. Selected base: Lifetime Labor and Tech Support, 3 Year Parts Warranty. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Free Puget Gear options
- None
- Surprise Me
- Socks
- Navy T-Shirt (Large)
- Navy T-Shirt (Medium)
- Navy T-Shirt (Small)
- Navy T-Shirt (XL)
- Navy T-Shirt (2XL)
- Navy T-Shirt (3XL)
- Navy T-Shirt (4XL)
- Mouse Pad
- Wireless Charger
- Power Bank
- Beanie
Official model choices. Selected base: None. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Courtesy Install options
- Chrome
- Firefox
- Adobe Creative Cloud Desktop App
- VLC
- LibreOffice Suite
- NVIDIA App
- Parsec
- LM Studio
Official model choices. Selected base: None selected. Compatibility, stock and price depend on the final configuration; confirm the completed order with Puget Systems.
Manufacturer options ↗Motherboard & Memory Expansion▾
| Motherboard model | ASUS ProArt X870E-Creator (AMD X870ESource & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Exact-device manufacturer specification section |
|---|---|
| Total RAM slots | UnpublishedSource & observationView specification source ↗Observed 2026-10-03T02:42:02.965142+00:00 Unpublished: no unambiguous exact-device manufacturer specification |
Independent testing
No published tests or reviewsBenchmarks & Reviews
No test results available (for now). A buying verdict is unavailable for this exact configuration.
