Winmate/Configurable
Winmate W10IW8M-RTD1ML
US · WINMATE-MODEL-W10IW8M-RTD1ML
BusinessConfigurable device · Advertised base configuration
Configurable modelWINMATE-MODEL-W10IW8M-RTD1ML
The hardware
Full Specifications
Configuration choices and fixed specifications. Upgrade limits do not guarantee an orderable choice.
Performance — CPU / GPU▾
| Graphics | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
Documented processor specifications and options
- Intel Core i5-8265U 1.6GHz (up to 3.9GHz)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Memory & Storage▾
| Installed RAM | 4 GBSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
Documented memory specifications and options
- 4GB SODIMM DDR4-2400 (Default)
- 8GB SODIMM DDR4-2400 (Optional)
- 16GB SODIMM DDR4-2400 (Optional)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Documented storage specifications and options
- 1 x 128GB M.2 SSD (Default)
- 256GB M.2 SSD (Optional)
- 512GB M.2 SSD (Optional)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Display▾
| Screen technology | Unpublished |
|---|---|
| Size | 10.1 inSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
| Resolution | 1920x1080 pxSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
| Refresh rate | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Battery & Power▾
| Battery capacity | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Power supply | Power Rating: 9-36V DC in (MIL-DTL-38999/1 connector) · Adapter: 100-240V, 50-60Hz / 19V DCSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Connectivity▾
| Ports | USB Port: 2 x USB 3.0 · Serial Port: 1 x RS232/RS422 /485 + 1 x RS422 Port(MIL-STD-38999 connector) · LAN: 2 x RJ45-10/100/1000 Mbps LAN(MIL-STD-38999 connector) · Video: 1 x HDMI · Audio: 2 x 1 Watt Speaker · Indicator: 4x LED Indicator for Power, Battery, SSD, RF statusSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
WWAN choices
- 4G/ LTE or 3G (Optional)
Optional radios, antennas and cellular service are not included by default.
Manufacturer options ↗GNSS choices
- Supports GPS (Default)
- GLONASS, Galileo, BeiDou (Optional)
Optional radios, antennas and cellular service are not included by default.
Manufacturer options ↗Build & Physical▾
| Weight | 2400 gSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Dimensions | Dimension: 266 x 222 x 50.5 mmSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Software & Bundle▾
| Included bundle | Adapter and PowerCord · Standard Battery · Stylus · Stand with Integrated Handle · Power/RS232 External Cable · LAN/USB2.0 External CableSource & observationView specification source ↗Observed 2026-10-09T21:58:05.072637+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
Documented operating system specifications and options
- Windows 10 IoT Enterprise (64 bit) (Default)
- Linux Ubuntu 20.04 (Optional)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Shock choices
- USA: MILSTD810H Method 516.8 Procedure I
- NATO: STANAG 4370/AECTP400 Edition 3 Method AECTP
- 402–Procedure I (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Vibration choices
- USA: MILSTD810H Method 514.8 Procedure I
- NATO: STANAG 4370/AECTP400 Edition 3 Method AECTP
- 401–Procedure I (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Drop choices
- USA: MILSTD810H Method 516.8, 4 ft
- NATO: STANAG 4370/AECTP400 Edition 3 Method AECTP 404– Procedure II, 4 ft (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗TEMPEST choices
- USA: NSA NSTISSAM TEMPEST/192 (Optional)
- NATO: SDIP27 (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Optional Accessory choices
- Kickstand (Optional)
- Vehicle Charger (Optional)
- Battery Charger (Optional)
- Shoulder Strap (Optional)
- Carry Bag (Optional)
- Stylus (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Independent testing
No published tests or reviewsBenchmarks & Reviews
No test results available (for now). A buying verdict is unavailable for this exact configuration.
