Winmate M900PT
US · WINMATE-MODEL-M900PT
BusinessConfigurable device · Advertised base configuration
Configurable modelWINMATE-MODEL-M900PT
The hardware
Full Specifications
Configuration choices and fixed specifications. Upgrade limits do not guarantee an orderable choice.
Performance — CPU / GPU▾
| Graphics | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
Documented processor specifications and options
- Intel Pentium N4200 1.1GHz (up to 2.5GHz)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Memory & Storage▾
| Installed RAM | 4 GBSource & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
Documented memory specifications and options
- 4GB (Default)
- 8GB (Optional)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Documented storage specifications and options
- 128 GB SSD
- Additional storage available with micro SDXC card slot (Default)
- 256 GB SSD (Optional)
- 512 GB SSD (Optional)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Display▾
| Screen technology | Unpublished |
|---|---|
| Size | 8 inSource & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
| Resolution | 1280x800 pxSource & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
| Refresh rate | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Battery & Power▾
| Battery capacity | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Power supply | Power Rating: 19V DC · Adapter: 100-240V, 50-60Hz / 19V DCSource & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Connectivity▾
| Ports | USB Port: 1 x USB 3.0 (Type A), 1 x USB 3.0 (Type C) · Audio: 1 x Audio combo 3.5mm audio combo jack · Audio: Dual Digital Mic With Noise Cancellation · Audio: Dual Speaker · SD Card Slot: 1 x Micro SDXC Slot · SIM Card Slot: 1 x Micro SIM card slot · Expansion Port: 1 x 15-pin D-sub connector for Power Input, USB 2.0,Audio Out, and Tx/ Rx · Indicator: 4x LED Indicator for Power, Battery, HDD, RF status · Docking Connector: 1 x 19-pin docking connectorSource & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
WWAN choices
- 4G LTE (Optional)
Optional radios, antennas and cellular service are not included by default.
Manufacturer options ↗Build & Physical▾
| Weight | 900 gSource & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Dimensions | Dimension: 225 x 148 x 20.5 mm ( 10 x 7.76 x 0.8 inches)Source & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Software & Bundle▾
| Operating system | Windows 10 IoT Enterprise (64 bit)Source & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Included bundle | Adapter and Power Cord · Standard Battery PackSource & observationView specification source ↗Observed 2026-10-09T21:58:03.773046+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Optional Accessory choices
- Desk Dock (Optional)
- Vehicle Dock (Optional)
- Vehicle Gateway (Optional)
- Vehicle Cradle (Optional)
- Battery Charger (Optional)
- Vehicle Charger (Optional)
- Hand Strap (Optional)
- Capacitive Stylus (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Barcode Scanner choices
- 1D/2D barcode reader (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Independent testing
