Winmate/Configurable
Winmate M900AD
US · WINMATE-MODEL-M900AD
BusinessConfigurable device · Advertised base configuration
Configurable modelWINMATE-MODEL-M900AD
The hardware
Full Specifications
Configuration choices and fixed specifications. Upgrade limits do not guarantee an orderable choice.
Performance — CPU / GPU▾
| Graphics | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
Documented processor specifications and options
- Intel Core i5-1235U
- Intel Core 5 processor 120U (Optional)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Memory & Storage▾
| Installed RAM | 8 GBSource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
Documented memory specifications and options
- 8GB (Default)
- 16GB (Optional)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Documented storage specifications and options
- 256GB SSD (Default)
- 512GB SSD (Optional)
- 1TB SSD (Optional)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Display▾
| Screen technology | Unpublished |
|---|---|
| Size | 8 inSource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
| Resolution | 1280x800 pxSource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
| Refresh rate | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Battery & Power▾
| Battery capacity | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Power supply | Power Rating: 20V DC · Adapter: 100-240V, 50-60Hz / 20V DCSource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Connectivity▾
| Ports | USB Port: 1 x USB 3.0 (Type A), 2 x USB 3.0 (Type C, Lockable, support Power Delivery 20V In and ALT mode) · LAN: 1 x RJ45-10/100/1000 GigaLAN port · Audio: Dual Digital Mic · Audio: Dual Speaker · SIM Card Slot: 1 x Nano SIM card slot · Indicator: 4x LED Indicator for Power, Battery, HDD, RF status · Docking Connector: 1 x 19-pin docking connectorSource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
WWAN choices
- 4G LTE (Optional)
- 5G (Optional)
Optional radios, antennas and cellular service are not included by default.
Manufacturer options ↗Build & Physical▾
| Weight | 1000 gSource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Dimensions | Dimension: 226.5 x 147.8 x 26.8 mmSource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Software & Bundle▾
| Included bundle | Adapter and Power Cord · Standard BatterySource & observationView specification source ↗Observed 2026-10-09T21:58:03.437230+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
Documented operating system specifications and options
- Windows 11 IoT Enterprise LTSC (64 bit) (Default)
- Windows 10 IoT Enterprise LTSC (64 bit) (Optional)
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗RFID choices
- HF RFID 13.56 MHz reader (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗EMC choices
- USA:
- MIL-STD-461G CE101, CE102, RE101, RE102, CS118(Default) (Default)
- MIL-STD-461G CS101, CS114, CS115, CS116, RS101, RS103 (Optional)
- MIL-STD-461G RE102 Ground Army Grade (Optional)
- NATO:
- STANAG 4370/AECTP501 NCE01, NCE02, NRE01, NRE02, NCS12(Default)
- STANAG 4370/AECTP501 NCS01, NCS07, NCS08, NCS09, NRS01, NRS02 (Optional)
- STANAG 4370/AECTP501 NRE02-2 Land Environment (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Optional Accessory choices
- Battery Charger (Optional)
- Vehicle Charger (Optional)
- Hand Strap (Optional)
- Lockable USB-C cable (Optional)
- Capacitive Stylus (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Independent testing
No published tests or reviewsBenchmarks & Reviews
No test results available (for now). A buying verdict is unavailable for this exact configuration.
