Exact configurationCMNF5A00AUS2461
The hardware
Full Specifications
Every published specification, grouped by category. Select a heading to collapse.
Performance — CPU / GPU▾
| Processor | AMD Ryzen 7 H 255Source & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Graphics | AMD Radeon 780MSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Memory & Storage▾
| Installed RAM | 24 GBSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Total storage | 1 TBSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Display▾
| Screen technology | Not applicable |
|---|---|
| Size | Not applicableSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
| Resolution | Not applicableSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
| Refresh rate | Not applicableSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Battery & Power▾
| Battery capacity | UnpublishedSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Power supply | DC 19 V-6,3 A, 5.5 x 2.5 mm DC connectorSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Connectivity▾
| Ports | 2 x 10/100/1000 Mbps/2.5 Gbps auto-negotiating RJ45 Gigabit Ethernet ports · 2 x USB 3.2 Gen 2 Type-A ports (10 Gbps) – front panel · 1 x USB 3.2 Gen 2 Type-A port (10 Gbps) – rear panel · 1 x USB 2.0 Type-A port – rear panel · 2 x USB4 Type-C (Supports DP 1.4, 4K@60Hz, up to 40Gbps data transfer, PD output) · 1 x DC IN · 1 x HDMI 2.1 · 1 x DP 2.1 · 1 x 3.5mm Audio Jack · 1 x Power Button · 1 x OCuLink Port (Supports external discrete graphics) · HDMI 2.1 x1 (8K@60Hz） · USB4 Type-C x2 · DP2.1 x1 (8K@60Hz) · 3.5 mm Audio Jack ×1Source & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Wireless & networking | WiFi 6E · Bluetooth 5.2Source & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Build & Physical▾
| Weight | UnpublishedSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Dimensions | 130 × 132 × 62mmSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Software & Bundle▾
| Operating system | Windows 11 PROSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Included bundle | Unpublished |
Motherboard & Memory Expansion▾
| Motherboard model | UnpublishedSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 Unpublished: no unambiguous exact-device manufacturer specification |
|---|---|
| Total RAM slots | UnpublishedSource & observationView specification source ↗Observed 2026-09-27T20:07:10.060734+00:00 Unpublished: no unambiguous exact-device manufacturer specification |
Independent testing
No published tests or reviewsBenchmarks & Reviews
No test results available (for now). A buying verdict is unavailable for this exact configuration.
