Exact configurationCMNS3A00BUS165G
The hardware
Full Specifications
Every published specification, grouped by category. Select a heading to collapse.
Performance — CPU / GPU▾
| Processor | AMD Ryzen 7 H 255Source & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Graphics | AMD Radeon 780MSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Memory & Storage▾
| Installed RAM | 16 GBSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Total storage | 512 GBSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Display▾
| Screen technology | Not applicable |
|---|---|
| Size | Not applicableSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
| Resolution | Not applicableSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
| Refresh rate | Not applicableSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Battery & Power▾
| Battery capacity | UnpublishedSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Power supply | DC 19V/6.3A, DC Header 5.5*2.1mmSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Connectivity▾
| Ports | 2.5GbE (10/100/1000/2500Mbps adaptive) LAN ×1 · USB3.2 Gen2 Type-A Port *2 (10Gbps, front interface) · USB3.2 Gen1 Type-A Port *4 (5Gpbs, rear interface) · USB4 Type-C *1 · DC IN *1 · HDMI 2.1 *1 · DP2.0 *1 · 3.5mm Audio Jack *1 · Power Button *1 · HDMI 2.1 (8K@60Hz) *1 · USB4 Type-C (8K@60Hz/ 4K@120Hz) *1 · DP2.0 (8K@60Hz/ 4K@120Hz) *1 · 3.5mm Audio Jack *1Source & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Wireless & networking | WiFi 6E · BT5.2Source & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Build & Physical▾
| Weight | UnpublishedSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Dimensions | 135*162.7*71.8 mmSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
Software & Bundle▾
| Operating system | Windows 11 ProSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 ACEMAGIC US exact fixed variant and CPU-matched specification panel |
|---|---|
| Included bundle | Unpublished |
Motherboard & Memory Expansion▾
| Motherboard model | UnpublishedSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 Unpublished: no unambiguous exact-device manufacturer specification |
|---|---|
| Total RAM slots | UnpublishedSource & observationView specification source ↗Observed 2026-09-27T20:07:19.108208+00:00 Unpublished: no unambiguous exact-device manufacturer specification |
Independent testing
No published tests or reviewsBenchmarks & Reviews
No test results available (for now). A buying verdict is unavailable for this exact configuration.
