Winmate/Specialty Devices
Winmate FM12Q9
US · WINMATE-MODEL-FM12Q9
BusinessConfigurable device · Advertised base configuration
Configurable modelWINMATE-MODEL-FM12Q9
The hardware
Full Specifications
Configuration choices and fixed specifications. Upgrade limits do not guarantee an orderable choice.
Performance — CPU / GPU▾
| Graphics | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|
Documented processor specifications and options
- Qualcomm 6490, Octa-Core, up to 2.7GHz
Official default is used only when stated or unambiguous. Optional capacities, additional drives and OS alternatives are not installed base hardware. Capacity limits are capabilities, not confirmation that every intermediate size is orderable. Source conditions apply; confirm the ordered combination with Winmate.
Manufacturer options ↗Memory & Storage▾
| Installed RAM | 8 GBSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Total storage | 128 GBSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Display▾
| Screen technology | Unpublished |
|---|---|
| Size | 12.1 inSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
| Refresh rate | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Panel Brightness choices
- 400 nits(Default)
- 800 (Optional)
Optional screen hardware is separate from the stated native screen.
Manufacturer options ↗Battery & Power▾
| Battery capacity | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Power supply | Power Rating: Docking: 10V-60V with ignition control · Power Rating: Tablet: 12V DC InSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Connectivity▾
WWAN choices
- 4G (Optional)
- 5G (Optional)
Optional radios, antennas and cellular service are not included by default.
Manufacturer options ↗Antenna connector choices
- SMA Connector(female) for external antenna WLAN (Tablet)
- SMA Connector(female) for external antenna GPS (Docking)
- SMA Connector(female) for external WWAN/5G antenna (Optional)
Optional connectors and dock-specific interfaces retain their source scope and mutual exclusions.
Manufacturer options ↗Build & Physical▾
| Weight | 1700 gSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Dimensions | Dimension: Tablet: 307 x 225 x 41 mm · Dimension: Docking: 202 x 245 x 52 mmSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Software & Bundle▾
| Operating system | Android 15.0Source & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
|---|---|
| Included bundle | 5M Power Cable with Fuse Kit · 0.3M USB Cable · 0.15M Power Converter Cable · DC Jack Power Cable · 84W Adapter with power cable · Cable Clamp Kit · WLAN Antenna x 2 · Quick Start Guide · External Antenna Fixing Bracket · Dock + Latch Locking Key · Stylus Kit + ScrewSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Exact official model technical rows; stated defaults separated from optional hardware |
Panel Brightness choices
- 400 nits(Default)
- 800 (Optional)
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Mounting choices
- RAM mount/ VESA mount
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Optional Accessory choices
- 1.8M RS232 Cable
- 0.3M Audio Cable
- 1.8M CAN BUS Cable
- 1.8M CAN BUS Open Wire Cable
- 2M IP65 LAN Cable
- GPS & LTE 2M Combo Antenna(VM240)
- GPS & LTE 5M Combo Antenna (VM9C)
- Magnetic Combo Antenna (VM10S)
- WWAN Antenna
- USB-C to HDMI Adapter
Source wording and mutual exclusions retained. Optional modules, mounts, batteries and external accessories are not included by default.
Manufacturer options ↗Motherboard & Memory Expansion▾
| Motherboard model | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Unpublished: no unambiguous exact-device manufacturer specification |
|---|---|
| Total RAM slots | UnpublishedSource & observationView specification source ↗Observed 2026-10-09T21:57:11.364383+00:00 Unpublished: no unambiguous exact-device manufacturer specification |
Independent testing
No published tests or reviewsBenchmarks & Reviews
No test results available (for now). A buying verdict is unavailable for this exact configuration.
